The RackPortPM16 is a 19" power monitor for retrofitting.Voltage/current display for easy looping into 3-phase supply lines, existing distribution racks.only one height unit (1U = 4.44cm)Specific features:Rack mounting: Front / Rear / Depth adjustable3x digital display voltmeter ammeter for each phase40-400V/100A precise digital meter voltmeter ammeterLCD screen with wide viewing angleswitchable backlightVoltage measurement range: 40-400V, measurement accuracy: ± 1%Current measurement range: 0-100AStarting current: 0.02A, measurement accuracy: ± 1%1m Cable in/outConnections:1x CEE16-In1x CEE16-OutTechnical data:

The RackPortWD16 is an intelligent and smart power monitor for connecting to 3-phase 125 amp supply lines.Voltage/current display for looping into 3-phase supply linesonly one height unit (1U = 4.44cm) Specific features: Measurement of all 3x external conductorsWatchDog function for limit valuesPower measurement on each channelWeb server for monitoring and configurationEthernet, Wi-Fi, MQTT, Bluetooth...Performance measurement with data storageSmart schedules, scripting, webhooksN conductor measurement3x digital display voltmeter ammeter, blue for each phase Voltage measurement range: 60V to 500V, measurement accuracy ‎±1Current measurement: 0 to 100 A, measurement accuracy ±11m Cable in/outShelly Pro 3EMOptional: switching output Connections: 1x Ethernet 1x CEE16-In1x CEE16-Out Technical data:

The RackPortPM32 is a 19" power monitor for retrofitting.Voltage/current display for easy looping into 3-phase supply lines, existing distribution racks.only one height unit (1U = 4.44cm)Specific features:Rack mounting: Front / Rear / Depth adjustable3x digital display voltmeter ammeter for each phase40-400V/100A precise digital meter voltmeter ammeterLCD screen with wide viewing angleswitchable backlightVoltage measurement range: 40-400V, measurement accuracy: ± 1%Current measurement range: 0-100AStarting current: 0.02A, measurement accuracy: ± 1%1m Cable in/outConnections:1x CEE32-In1x CEE32-OutTechnical data:

The RackPortWD32 is an intelligent and smart power monitor for connecting to 3-phase 125 amp supply lines.Voltage/current display for looping into 3-phase supply linesonly one height unit (1U = 4.44cm) Specific features: Measurement of all 3x external conductorsWatchDog function for limit valuesPower measurement on each channelWeb server for monitoring and configurationEthernet, Wi-Fi, MQTT, Bluetooth...Performance measurement with data storageSmart schedules, scripting, webhooksN conductor measurement3x digital display voltmeter ammeter, blue for each phaseVoltage measurement range: 60V to 500V, measurement accuracy ‎±1Current measurement: 0 to 100 A, measurement accuracy ±11m Cable in/outShelly Pro 3EMOptional: switching output Connections: 1x Ethernet 1x CEE32-In1x CEE32-Out Technical data:

The RackPortPM63 is a 19" power monitor for retrofitting.Voltage/current display for easy looping into 3-phase supply lines, existing distribution racks.only one height unit (1U = 4.44cm)Specific features:Rack mounting: Front / Rear / Depth adjustable3x digital display voltmeter ammeter for each phase40-400V/100A precise digital meter voltmeter ammeterLCD screen with wide viewing angleswitchable backlightVoltage measurement range: 40-400V, measurement accuracy: ± 1%Current measurement range: 0-100AStarting current: 0.02A, measurement accuracy: ± 1%1m Cable in/outConnections:1x CEE63-In1x CEE63-OutTechnical data:

The RackPortWD63 is an intelligent and smart power monitor for connection to 3-phase 125 amp supply lines.Voltage/current display for looping into 3-phase supply linesonly one height unit (1HE = 4.44cm) Specific features: Measurement of all 3x outer conductorsWatchDog function for limit valuesPower measurement on each channelWeb server for monitoring and configurationEthernet, Wi-Fi, MQTT, Bluetooth...Performance measurement with data storageSmart schedules, scripting, webhooksN-conductor measurement3x digital display voltmeter ammeter, blue for each phaseVoltage measuring range: 60 V to 500 V, measuring accuracy ‎±1Current measurement: 0 to 100 A, measurement accuracy ±11m cable in/outShelly Pro 3EMOptional: Switching output Connections: 1x Ethernet 1x CEE63-In1x CEE63-Out Documentation:  User Manual   Technical data:

RackPortMain1 - Versatile 1U MiniServer for System Monitoring and MoreThe RackPortMain1 is a compact 1U MiniServer, perfect for use as a central unit for Watchdog system monitoring. Featuring a freely configurable Raspberry Pi 5 web server on a Linux basis, it offers countless application possibilities. Use it to display WiFi power monitors, load cells, or any other external applications that respond to threshold exceedances or timers.Thanks to the open operating system and the powerful Raspberry Pi 5, the possibilities are virtually limitless.Key Features:Raspberry Pi 5: Open Linux system as a foundation with pre-installed Docker containersHomeAssistantNode-RedInfluxDBMosquittoExtensive Communication Options: Web server, MQTT, ModBus, HTML, Bluetooth, etc.High Operational Stability: SSD (Solid State Drive) for enhanced stabilityPowerful Hardware:25W power supply via GPIO portInternal 8-port 1Gbit switchVersatile Connectivity:1x Powercon True1 In1x Powercon True1 Out7x Ethernet (6x Front, 1x Rear)3x USB2x HDMI2x Extension ports for custom purposes like DMX or GPIOsTechnical Specifications:ARM Cortex 2.4GHz8GB RAM128GB SSD230VAC, 30WAdditional Resources:Find links to installation scripts and templates here:WatchDog (current, voltage, power, CosPhi…)Load cellsTemperature sensorsWind sensors User-Manual-Rigport-StagePort_de_V0-1User_Manual_WatchDog
